Mustang® Modular Analyzer Distribution Panel (MMADP®)
Mustang® Modular Analyzer Distribution Panel (MMADP®)
The Mustang® Modular Analyzer Distribution Panel supplies up to four different analyzers with low pressure gas samples from a single source. This eliminates the need for multiple sample points and reduces the cost of required sampling devices. The individual sample streams are independent of one another and eliminate the chance of active streams being effected by other streams coming on or off line.
The MMADP is primarily used within the Natural Gas industry to supply up to four different analyzers with low pressure gas samples from a single source.
Features
- Modular design
- Inlet filter and gauge
- Up to four (4) pressure regulated outlets with gauges
- Integral valving
- Regulator kit
Benefits
- Securely fits inside a heated cabinet
- Easy to install, maintain, and troubleshoot
- Provides four individual outlet pressures with one single inlet pressure
Specifications
| Maximum allowable working pressure | 200 psig (14 bar) |
|---|---|
| Temperature range | 225°F (107°C) |
| Port sizes | 1/8” female NPT |
| Wetted materials | Machined parts: 316 stainless steel/NACE compliant All other metal parts: stainless steel/NACE compliant |
| Electrical enclosure classification | Class 1, Division 1, Group D (with optional electrical enclsoure) |
| Cabinet Construction | Hotpressed Glass Fiber Reinforced Polyester (with optional electrical enclosure) |
| Heating components | 50 watt self-limiting block heater (with optional electrical enclosure) |
| Regulator | Mustang® Heated Regulator (up to 4) |
| Outlet pressure range | 0-10 (0-0.69 bar) 0-25 (0-1.72 bar) 0-50 (0-3.45 bar) 0-100 (0-6.89 bar) |
| Seal | Neoprene |
| Coating | Sulfinert® optional inert silicon coating |
| Input Supply Voltage Options | 120 VAC 240 VAC 24 VDC (with optional electrical enclosure) |
