Mustang® NGL JR Vaporizer Sampling System
Mustang® NGL Junior Vaporizer Sampling System
The Mustang Pressure Regulating Vaporizer Sample Conditioning System Jr. (MPRVSSJR) combines a Mustang® Vaporizer and Mustang® Heated Regulator with a PID temperature controller to create a simple, single-path sample conditioning system for natural gas liquids.
- Analytically Accurate® Technology
- cETLus Certified
- Patented Technology
- Continuous gas flow design eliminating post-vaporization hydrocarbon liquid dropout
- Accurate and reliable representative sample for your GC
- Installs at gas stripping facilities and where heavier hydrocarbon measurements are required
A representative sample is delivered to a flash chamber within the vaporizer, preventing pre-vaporization. An independently controlled electric cartridge heater, with sufficiently large surface area, maintains a stable gas temperature throughout the process. Pre- and post- regulation heat exchangers, along a tortuous gas path in the Mustang Heated Regulator, ensure sample and phase stability for introduction into natural gas analyzers.
Features
- Patented technology
- Continuous gas flow design
- Vented cabinet having a gas sample input
- Pressure regulator
- Single path vaporizer
- Heated regulator
- Electrically certified communications port
Benefits
- Provides an accurate and reliable representative sample to the Gas Chromatograph
- Eliminates post-vaporization hydrocarbon liquid dropout
- Reduces the incoming liquid pressure
Certifications
- cETLus Certifiable
Specifications
| Maximum Allowable Operating Pressure | 3750 psig (359 bar) |
|---|---|
| Proportional Temperature Control Range | 0ºF to 300ºF (-18ºC to 148ºC) |
| Port Sizes | 1/4” female NPT |
| Conduit Sizes | 3/4” female NPT |
| Electrical Enclosure Classification | Class 1, Division 1 & 2, Groups C, D, T3 |
| Wetted Materials | Machined parts: 316 stainless steel/NACE compliant All other metal parts: stainless steel/NACE compliant (other materials available upon request) |
| Power Rating Options | 115 VAC, 815 Watts, 50/60 Hz, ± 10% 208/230 VAC, 815 Watts, 50/60 Hz, ± 10% |
| Regulator | MHR Single Stage Regulator MJTHR Multi-Stage Regulator |
Mustang Pressure Regulating Sample Conditioning System Jr Cut Sheet
